Descriptio:
Series MT-NSX casuum formatorum ambitus praevaricatores (MCCBs) firmum et versatile praesidium systematum electrica low-voltages, late in plantis industrialibus, aedificiis mercatoriis, et inceptis criticis infrastructuris inceptis adhibitis. Disposito ad salutem et efficaciam, hi praevaricatores constantem observantiam tradent sub condicionibus operationibus exigendis.
| | |
Applicationes:
MT-NSX MCCB elementum essentiale est ad circuitus electricos tuendos et apparatum connexum. Iter eius commodabile occasus et robusti intermissionis facultatem reddunt aptam ad coordinationem selectivam in retiacula electrica complexa. Typicam applicationes includit:
Distributio tabularum et tabularum principalis potestas
Motricium imperium centra et tabulata starter
Generator et tergum potentia praesidium
Machinaria industriae potentiae copia systemata
Commercial and office building electrical circuitus
Renovabilia systemata navitatis, inter officinas solares et ventos
 | |
 |  |
ONERO praesidium
Components scelerisque utere (denumenta bimetallica) vel machinas electronicas emissio ad monetam currentem.
Cum current valorem statutum excedit et per certum temporis spatium durat, elementum scelerisque flectit ob calorem (vel unitas electronic signum mittit), mechanicam mechanismum excitat ad disiungendum ambitum et ne circumigendo exardescit.
Brevis circuitus praesidium
Impleta per emissionem electromagneticam (coil et nucleum ferreum).
Cum brevis circuitus incidit, instantaneus altus vena magnum campum magneticum gignit, qui armaturam ad collidendum cum mechanismo emissione impellit et celeriter intra milliseconds disiunget, reprimendo culpam current.
MCCB Instantaneous Test
MCCB Temperature Rise Test Bench
MCCB Temperature Rise Test Bench
MCCB Temperature Rise Test Bench
MCCB Temperature Rise Test Bench
MCCB Assemble
MCCB Assemble
MCCB Temperature Rise Test Bench
Ad translationem salutem obtinendam, fructus electrica nostri exportantur in cratibus ligneis aucti. Crates caloris curationem subeunt et ISPM-15 ferunt signum, ut celeris consuetudines alvi ferant. In consilio basi elevato operationem forklift faciliorem facit, cum collisio-absorbens ligamen internum efficit ut fructus integros perveniant. Crates exteriores omnes perspicue intitulati sunt et logisticis internationalibus signis obtemperant.
Power transmission successful
Photovoltaic Grid-Connected Cabinet Utilising ACB and MCCB
Box-typesubstation ACB VCB MCCB
Box-typesubstation ACB VCB MCCB
Box-typesubstation ACB VCB MCCB
| Item No. | NSX100-250 | NSX400-630 | |
| Numerus polorum | 3P, 4P | ||
| Imperium | Manual | cum togglewith directum vel extensum in gyratorio manubrio | |
| hospites | certum | ante hospites | |
| certum | Plug-in | ante hospites/rear connections | |
| Notae electricae (per IEC60947 et EN60947-2) | |||
| Ratum current | In (A) | 16,25,32,40,50,63,80,100,125,160,200,250 | 400,500,630 |
| Nulla voltage rated | Ui(V) | 800 | |
| Rated impetus sustinere voltage | Uimp(kV) | 8 | |
| Rated operational voltage | Ue(V) | AC 50/60Hz,690 | |
| Utendo genus | A | ||
| Facultatem fractionis levels | F、N、H | ||
| Capacitas fracta (kA rms) AC 50/60 Hz 380/415 V | Icu | XXXVI, 50, 70 | |
| Servitium facultatem frangendi (kA rms) AC 50/60 Hz 380/415 V | Ics | XXXVI, 50, 70 | |
| Operatio perficientur | Mechanica | 20000 | 10000 |
| Electrical | 10000 | 5000 | |
| Praesidium | TMD, Micrologic | ||
| Indicio ac potestate auxiliorum | |||
| Auxiliares switch | |||
| MX Shunt coil | ■ | ||
| MN sub-voltage coil | ■ | ||
| Exemplar | MTEZC-100 | MTEZC-125 | MTEZC-250 | MTEZC-400 | MTEZC-630 | |
| Testa current | Inm(A) | 100A | 125A | 250A | 400A | 630A |
| Rated voltage working | Ue(v) | AC415/550V | ||||
| Rated Insulating intentione | Ui(v) | 690V | ||||
| Rated impetus sustinere voltage | Uimp(kv) | 6kV | ||||
| Numerus polorum | 2P / 3P/4P | 3P | 2P / 3P/4P | 3P / 4P | 3P / 4P | |
| Rated limit brevis-circuitus capacitatis Icu (ka) o-co | 415V | 30-100 / 7.5-100 | 10-100 | 36-85 / 18-85 | 36-70 | 36-70 |
| 550V | 10-20 / 2.5-20 | 5-20 | 10-25/5-25 | 36-50 | 36-50 | |
| Rated breve spatium currens facultatem Ics fractionis (ka) | 110-400V | 100% ICU/25-50% ICU | 50% ICU | 50% ICU / 50% ICU | 100% (220-415V) | 100% (220-415V) |
| 415-550V | 25%ICU/25-50%ICU | 50% ICU | 50% ICU / 50% ICU | L%(440V) | L%(440V) | |
| Diuturnitatem | Mechanica | 13000 | 13000 | 10000 | 10000 | 10000 |
| Electrical | 4000 | 4000 | 5000 | 4000 | 3000 | |
